Technical Parameters Of fixed -wing UAVs

Tsau- tis UAVs muaj ntau qhov loj me, nrog UAVs me me muaj tisspans me me li 15 centimeters thiab loj UAVs muaj wingspans ntawm ob peb meters. Qhov siab tshaj plaws ntawm qhov hnyav hnyav ntau yam, los ntawm kilograms (xws li 1.9 kg RQ-11 "Raven") mus rau tons (xws li SA750U loj unmanned thauj aircraft nrog lub siab tshaj plaws takeoff hnyav ntawm 7.5 tons).

Lawv cov kev caij nkoj nrawm feem ntau yog li ntawm 30 txog 240 km / h, nrog qee qhov siab - cov qauv nrawm mus txog 340 km / h. Endurance muaj li ntawm 1 teev mus rau ntau tshaj 40 teev, thiab kev pab cuam ceilings li ntawm 5000 mus rau 8000 meters.

Kev them nyiaj ntau ntawm ob peb kilograms mus rau ntau tons; Piv txwv li, SA750U muaj qhov siab tshaj plaws payload muaj peev xwm ntawm 3.2 tons.

Txoj kev tshem tawm thiab tsaws yog hloov pauv thiab muaj ntau haiv neeg, txhawb nqa ntsug nqa tawm thiab tsaws (VTOL), tua catapult, thiab tes-lav. Kev khiav hauj lwm kub feem ntau yog li ntawm -20℃mus rau +55 degree, nrog qee cov qauv ua haujlwm ib txwm nyob rau hauv qhov kub thiab txias li -40 degree. Cua tsis kam yog feem ntau mus txog qib 6 (cua ceev 10.8-13.8 m / s) lossis siab dua.

Kev taw qhia thiab kev tswj hwm feem ntau txhawb nqa qhov chaw ntawm ntau lub satellite navigation systems xws li GPS, BDS (BeiDou), thiab GLONASS, thiab siv siab -precision real-time dynamic (RTK) sib txawv technology los txhim kho qhov chaw raug. Lub davhlau tswj system muaj tus cwj pwm tswj qhov tseeb, nrog qee cov qauv qhia txog tus cwj pwm lub kaum ntse ntse tsawg dua lossis sib npaug li 1℃hauv kev ntsuas qhov ntsuas zoo li qub.
